Sound Insulation Systems SONOTIZ
Professional Solutions for Acoustic Comfort
SONOTIZ materials provide effective protection against airborne and impact noise while maintaining a slim profile, fire resistance, and environmental safety. The core of most solutions is SONO Eco fiberglass, which is resistant to moisture, high temperatures, and mechanical stress.
The products are suitable for insulating floors, walls, ceilings, and technical zones in residential, commercial, and public buildings. All materials comply with European fire safety and acoustic performance standards.
Advantages:
- Comprehensive protection against noise and vibration
- Non-combustible and non-toxic components
- Easy to install and highly adaptable
- Effective thermal insulation
SONOTIZ BLOCK – Airborne Sound Insulation Panel
A rigid acoustic panel made of corrugated cardboard filled with quartz sand. Its high density and multilayer internal structure efficiently absorb mid- and high-frequency noise, all while being only 12–14 mm thick.
Key Features:
- Airborne noise reduction up to 52 dB (ISO 10140)
- Fire classification: A2:s1,d0
- Dry installation with no adhesives
- Panel size: 0.8 × 1.2 m (0.96 m²)
- Weight: 16.5–18.5 kg/m²
- Effective even in limited-space installations
Recommended For:
- Partition walls in apartment buildings
- Hotel room divisions
- Recording and listening rooms (studios, halls)
- Ceilings and partitions in office spaces
- Home theaters and multimedia rooms
- Renovation projects with limited wall thickness
SONOTIZ AT – Vibroacoustic Mat for Floors and Walls
A flexible thermoacoustic mat made of SONO Eco fiberglass with hydrophobic layers. Ideal for reducing impact noise, vibration, and heat loss. Highly resistant to pressure, humidity, steam, and high temperatures.
Key Features:
- Impact sound insulation up to 24 dB (ISO 10140)
- Thermal conductivity: ~0.034 W/m·K
- Density: 150 kg/m³
- Roll size: 1.5 × 10 m (15 m²)
- Fire classification: A2:d0:S1
- Weight: approx. 20 kg/roll
Recommended For:
- Floating floor installations under screed
- Interior walls and partitions
- Suspended and stretch ceiling systems
- Music and dance halls
- Technical zones with HVAC and piping
- Public buildings: schools, hospitals, offices
SONOTIZ ATA – Acoustic & Radiant Barrier Mat
A multilayer insulation material based on SONO Eco fiberglass with a metallized layer that reflects infrared radiation. Provides combined sound and thermal insulation even in extreme conditions.
Key Features:
- Impact noise reduction: up to 24 dB
- Thermal conductivity: 0.020 W/m·K
- Temperature resistance: up to 650°C
- Fire classification: A2:s1,d0
- Roll size: 1.5 × 10 m (15 m²)
- Weight: ~22 kg/roll
Recommended For:
- Attic and pitched roof insulation
- Installation under roofing and metal cladding
- Suspended ceilings and recesses
- Behind wall insulation or cladding systems
- Technical areas with temperature fluctuation
- Summer terraces, lofts, timber-frame houses
Have Questions? We’re Here to Help!
If you're unsure which material is right for your needs or want expert advice on acoustic performance and installation — reach out to our team. We’ll find the perfect solution for your project.
